lamaPLC project: Digitales Potentiometer Board Moduls
A digital potentiometer (or “digipot”), such as the Renesas X9C series, is a semiconductor device that replicates the function of a mechanical potentiometer—varying resistance—but replaces the manual knob with digital control signals.
Renesas X9C series
The X9C102, X9C103, X9C104, and X9C503 are digitally controlled (XDCP) potentiometers. The device consists of a resistor array, wiper switches, a control section, and nonvolatile memory. The wiper position is controlled by a three-wire interface.
The potentiometer is implemented using a resistor array composed of 99 resistive elements and a wiper-switching network. Between each element and at either end are tap points accessible to the wiper terminal. The position of the wiper element is controlled by the CS, U/D, and INC inputs. The wiper position can be stored in non-volatile memory and recalled upon subsequent power-up.
The device can be used as a three-terminal potentiometer or a two-terminal variable resistor in a wide variety of applications, from control to signal processing to parameter adjustment.
 |  |
Wiring
